Low rotation steel wire
Wire Right hand regular lay - Preformed.Galvanized.
Tensile strength: 1960 N/mm2
6 x (1-6) +WSC
|
Item no. |
Dim. mm |
Construction |
Approx. weight kg/m |
BLL kN |
BLL kP |
|
X35-0100-303Z |
10,0 |
35 x 7 + WSC |
0,45 |
76,0 |
7.747 |
|
X35-0110-303Z |
11,0 |
35 x 7 + WSC |
0,54 |
91,0 |
9.276 |
|
X35-0120-303Z |
12,0 |
35 x 7 + WSC |
0,65 |
107,0 |
10.907 |
|
X35-0130-303Z |
13,0 |
35 x 7 + WSC |
0,76 |
128,0 |
13.048 |
|
X35-0140-303Z |
14,0 |
35 x 7 + WSC |
0,88 |
148,0 |
15.087 |
|
X35-0150-303Z |
15,0 |
35 x 7 + WSC |
1,01 |
169,0 |
17.227 |
|
X35-0160-303Z |
16,0 |
35 x 7 + WSC |
1,15 |
194,0 |
19.776 |
|
X35-0180-303Z |
18,0 |
35 x 7 + WSC |
1,45 |
242,0 |
24.669 |
|
X35-0200-303Z |
20,0 |
35 x 7 + WSC |
1,79 |
301,0 |
30.683 |
|
X35-0220-303Z |
22,0 |
35 x 7 + WSC |
2,17 |
370,0 |
37.717 |
|
X35-0240-303Z |
24,0 |
35 x 7 + WSC |
2,58 |
441,0 |
44.954 |
|
X35-0260-303Z |
26,0 |
35 x 7 + WSC |
3,03 |
517,0 |
52.701 |
|
X35-0280-303Z |
28,0 |
35 x 7 + WSC |
3,51 |
599,0 |
61.060 |
|
X35-0300-303Z |
30,0 |
35 x 7 + WSC |
4,03 |
679,0 |
69.215 |
|
X35-0320-303Z |
32,0 |
35 x 7 + WSC |
4,59 |
769,0 |
78.389 |
|
X35-0340-303Z |
34,0 |
35 x 7 + WSC |
5,18 |
868,0 |
88.481 |
|
X35-0360-303Z |
36,0 |
35 x 7 + WSC |
5,81 |
903,0 |
92.049 |
Dimensions stated for information only. Other dimensions and constructions on request.
