TIMM WARP, 12-strand HMPE rope with cover
Acera Products Acera™ Warp is constructed from 12-strand core of Acera™ yarns with lead in the middle and 32-strand braided Acera™ cover protecting rope from wear and abrasion.CONSTRUCTION
FIBER
SPECIFIC GRAVITY
COLOURS
UV RESISTANCE
ABRASION RESISTANCE
ACID RESISTANCE
ALKALI RESISTANCE
MOST CHEMICALS RESISTANCE
COLD & FROST RESISTANCE
WATER RESISTANCE
HEAT RESISTANCE
ELONGATION
CHEMICAL RESISTANCE
12-strand braided core,
32-strand braided cover
AceraTM HMPE
0,97-1.6 g/m3,
customized lead-core
Platinium
Excellent
Excellent
Excellent
Excellent
Excellent
Excellent
Excellent
Low (145-150 melting)
Low (0-6% under 2,5 ton)
Excellent
Acera™ Warp is constructed from 12-strand core of Acera™ yarns with lead in the middle and 32-strand braided Acera™ cover protecting rope from wear and abrasion.
This unique single yarn coating process demonstrates the uncompromising commitment to the quality standards of Acera”’.
Single yarn coating is proven to significantly enhance internal and external abrasion resistance and extend service life and strength.
12-strand ropes are regarded as the best rope construction and has become the most common construction for HMPE ropes. Acera™ Amundsen is the alternative to the unique steel wire ropes. It is stronger and safer, with significantly less snap-back/recoil. The corresponding weight is therefore 7 time slower. When replacing conventional fiber ropes, the reduction in diameter leads to significant savings in weight (60%), space and handling. This reduces the total time required for mooring operations and fuel consumption.
Key benefits:
- Section length.
- End - Expert splice with Acera™.
- High strength.
- Excellent abrasion resistance.
- Reduced external damage and particle ingress.
Suitable for:
- Fishery
- Offshore
Item no. |
Diameter mm. |
MBL spliced (t) |
MBL spliced (kN) |
ACTW-16 |
16 |
23,5 |
230 |
ACTW-18 |
18 |
29,1 |
285 |
ACTW-20 |
20 |
34,7 |
340 |
ACTW-22 |
22 |
41,3 |
405 |
ACTW-24 |
24 |
47,9 |
470 |
ACTW-26 |
26 |
55,1 |
540 |
ACTW-28 |
28 |
62,7 |
616 |
